AB 1771-NR: High Precision Isolated Analog Modules, for Industrial Automation

Resolution:16-bit

Isolation Voltage:1000V AC

Input Range:±10V

Operating Temperature:-40°C to +85°C

Power Consumption:Less than 10mW

Communication Interface:RS-485

Mounting:Panel Mount

    The AB 1771-NR is engineered to meet the stringent demands of industrial control applications, featuring high precision and robust isolation technology. Its wide signal range and high-resolution capabilities make it ideal for applications requiring accurate measurement and control.

    This module operates within an extensive temperature range (-40°C to +85°C), ensuring reliable performance in various environmental conditions. The choice of signal ranges (±10V, ±5V, 0-10V, 4-20mA) caters to diverse measurement needs, enhancing its versatility.

    With a focus on safety and reliability, the AB 1771-NR incorporates high input impedance, minimizing the impact on the measurement circuit, and a 1000VDC isolation voltage, protecting against potential hazards in industrial environments.

    Equipped with an RS-485 interface, the module facilitates seamless data transfer in industrial networks, supporting multiple devices and protocols for enhanced system scalability and interoperability.

    Optimized for energy efficiency, the AB 1771-NR consumes ≤ 1W, reducing operational costs and environmental impact. Its compact size (75mm x 65mm x 20mm) and industry-standard 9-pin D-sub connector enable easy integration into existing systems, minimizing installation time and complexity.
