ABB BGAD-02C: High-Performance IGBT Module, for Industrial Control Systems

Technology Type:IGBT

Model Number:BGAD-02C

Rated Voltage:650V

Rated Current:200A

Operating Temperature Range:-40°C to +170°C

Package Type:TO-247-3

Insulation Resistance:≥10MΩ

Failure Rate at 175°C:< 1E-7/h

Max Gate Charge:≤10μC

Switching Frequency:Up to 50kHz

Peak Forward Current:1200A

Peak Reverse Voltage:800V

    The ABB BGAD-02C IGBT module stands out with its advanced semiconductor technology, engineered for superior power handling capabilities. Its robust design ensures reliable operation across a wide temperature range, making it ideal for use in heavy-duty industrial machinery.

    This module is optimized for applications requiring high switching speeds and low switching losses, significantly enhancing system efficiency. Its high insulation voltage guarantees safety and durability even under harsh conditions.

    Engineered with precision, the ABB BGAD-02C utilizes state-of-the-art materials to withstand mechanical stresses and environmental challenges, ensuring long service life and minimal maintenance requirements.

    Installation and integration are straightforward, thanks to its industry-standard dimensions and compatibility with existing power systems. Comprehensive documentation and support are provided for easy setup and troubleshooting.

    Backed by ABB’s commitment to quality and innovation, the BGAD-02C comes with a warranty that reflects our confidence in its performance. Trust in ABB for solutions that drive efficiency, reliability, and productivity in your operations.
