Model Type:Ethernet Motion Module
Manufacturer:Allen Bradley
Model Number:1756-EN3TR/B
Number of Axes Supported:3
Communication Interface:Ethernet/IP
Motion Control Protocol:EtherNet/IP
Max. Motor Power:Up to 3 HP
Encoder Compatibility:Up to 20,000 counts/revolution
Temperature Range:-20°C to 55°C
Operating Voltage:100 to 240V AC
Power Consumption:10W
Communication Speed:10/100 Mbps
Isolation:500Vrms
Enclosure Type:IP20
Connectivity:RJ45 Ethernet connector
Software Compatibility:ControlLogix 1756 Software Suite
The Allen-Bradley 1756-EN3TR/B ControlLogix Ethernet Motion Module is a robust solution for enhancing precision and performance in motion control systems. This module seamlessly integrates into the ControlLogix system architecture, providing advanced connectivity and processing capabilities.
Featuring an EtherNet/IP interface, it ensures reliable data transfer rates for real-time communication, crucial for complex industrial automation tasks. The rack-mounted design allows for flexible installation in various industrial environments, making it suitable for both new installations and retrofit scenarios.
With its extensive input/output capacity, the 1756-EN3TR/B can manage a wide range of signals from sensors and actuators, ensuring accurate control over machinery operations. Its compatibility with SERCOS III protocol facilitates seamless integration with a multitude of motion control devices, enhancing system efficiency and reliability.
The module supports various encoder types, enabling precise measurement and control of motion parameters. This feature is particularly valuable in applications requiring high accuracy, such as robotics, packaging lines, and material handling systems.
In terms of power consumption, the 1756-EN3TR/B operates efficiently, consuming less than 10 watts, which helps in reducing energy costs and environmental impact. Additionally, its operating temperature range (-25°C to +60°C) ensures reliable performance across different industrial climates.
